20. Bayesian regression

Language: Python (Jupyter notebook) - R version

Ported from bayesian_regression.py in the USACE-RMC Numerics-Python-Examples repository (0BSD licensed). The upstream script drives the C# Numerics.dll through pythonnet, handing the DEMCzs sampler a list of hand-picked Uniform priors and a Python log-likelihood callback. That callback-likelihood pattern is deliberately not exposed by corehydropy, so this version recasts the same regression through arimax_analysis (details below) and the reproduction is statistical rather than exact. The synthetic data, however, are bit-identical to the upstream script’s, and the R version of this example uses the same core and prints the same numbers.

What you’ll learn

  • How to regenerate the upstream script’s synthetic data exactly (same seeded Mersenne Twister).
  • How to express a Bayesian linear regression as an ARIMAX(0,0,0) model with a linear time trend.
  • What the returned curves are: the MAP fitted line and a posterior predictive band.

Synthetic data

The upstream script simulates a straight line with Normal noise: x = linspace(0, 10, 80) and y = a + b*x + Normal(0, sigma) with a = 2.0, b = 1.4, sigma = 1.2, drawing the noise with seed 123. The port keeps the C# Mersenne Twister bit-exact, so Distribution("Normal", ...).random with the same seed reproduces the upstream noise vector to the last bit. We write x as 10*t/79 for the time index t = 0..79, which is the same array as linspace(0, 10, 80) and makes the mapping used below explicit.

One quirk worth knowing about, since the upstream run sees the identical draw: this particular seeded noise vector runs light. Its sample standard deviation is 0.904, well under the nominal 1.2, so any faithful posterior for sigma concentrates near 0.9.

import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
import corehydropy as ch

n = 80
true_a, true_b, true_sigma = 2.0, 1.4, 1.2

t = np.arange(n)        # time index 0..79
x = 10.0 * t / 79.0     # identical to np.linspace(0, 10, 80)

noise = np.asarray(ch.Distribution("Normal", [0.0, true_sigma]).random(n, seed=123))
y = true_a + true_b * x + noise

print(f"first observations: {y[:4]}")
print(f"realized noise sd: {noise.std(ddof=1):.4f} (nominal {true_sigma})")
first observations: [2.61712676 2.85166215 1.67679187 2.31532347]
realized noise sd: 0.9037 (nominal 1.2)

Recasting the regression

The upstream script builds a C# List of three priors (Uniform(-10, 10) for a, Uniform(0, 5) for b, Uniform(0.1, 5) for sigma) and a Python callback that sums Normal(0, sigma).LogPDF(residual) over the data. Neither custom priors nor likelihood callbacks are part of the public API here. But regression on the time index is a built-in model: arimax_analysis with orders p = d = q = 0, an intercept, and trend="Linear" fits

\[y_t = \mu + \gamma t + \varepsilon_t, \qquad \varepsilon_t \sim \text{Normal}(0, \sigma),\]

which is Bayesian simple linear regression, sampled with the same DEMCzs sampler the upstream uses. Because x = 10t/79 is an affine map of the time index, the upstream parameters translate directly:

  • intercept: \(a = \mu\), so the true value is 2.0;
  • slope: \(\gamma = b \cdot 10/79\), so the true trend per time step is \(1.4 \cdot 10/79 = 0.17722\), and the fitted slope maps back as \(b = \gamma \cdot 79/10\);
  • sigma is the residual standard deviation in both parameterizations.

Two honest differences from the upstream run. First, the priors are the model’s own data-scaled uniforms (order-of-magnitude bounds built around a least-squares initialization), not the upstream’s hand-picked ones, so posterior numbers can only be compared statistically. Second, the runtime: the upstream script takes about five minutes because every likelihood evaluation crosses back into Python; here the likelihood is compiled, and the modest settings below finish in about a second.

parameters in the returned dict is the posterior mode (MAP) vector, in model order: intercept \(\mu\), trend \(\gamma\), then \(\sigma\) last.

fit = ch.arimax_analysis(
    y,
    order_p=0, order_d=0, order_q=0,  # no AR, differencing, or MA terms
    trend="Linear",                   # deterministic trend gamma * t
    include_intercept=True,           # intercept mu
    training_time_steps=n,            # fit on all 80 points
    forecasting_time_steps=0,
    sampler="DEMCzs",                 # the sampler the upstream script uses
    iterations=2000,
    output_length=5000,
    credible_level=0.90,
    seed=45678,
)

mu_map, gamma_map, sigma_map = fit["parameters"]
b_map = gamma_map * 79.0 / 10.0  # slope per time step -> slope per unit x

summary = pd.DataFrame({
    "parameter": ["intercept a", "slope b", "slope per step gamma", "sigma"],
    "truth": [true_a, true_b, true_b * 10.0 / 79.0, true_sigma],
    "MAP": [mu_map, b_map, gamma_map, sigma_map],
})
print(summary.to_string(index=False))
print(f"\nrmse: {fit['rmse']:.4f}")
           parameter    truth      MAP
         intercept a 2.000000 2.043677
             slope b 1.400000 1.391644
slope per step gamma 0.177215 0.176157
               sigma 1.200000 0.918454

rmse: 0.8977

All three parameters land close to the generating values, with sigma tracking the realized noise level (0.904) rather than the nominal 1.2, exactly as the upstream run does with the same data.

Fitted line and band

What the returned curves are, since they differ from the upstream plot:

  • mode_curve is the deterministic fitted line \(\mu + \gamma t\) evaluated at the MAP parameters.
  • mean_curve, lower_ci, and upper_ci come from a posterior predictive ensemble: each posterior draw simulates a full series including observation noise. The 90% band is therefore a predictive band for observations, wider than the mean-function credible band the upstream script plots.

The upstream 2x2 figure also shows posterior histograms of a, b, and sigma; the analysis returns curves and MAP values rather than raw chains, so those two panels cannot be reproduced here.

mode_curve = np.asarray(fit["mode_curve"])
lower = np.asarray(fit["lower_ci"])
upper = np.asarray(fit["upper_ci"])
true_line = true_a + true_b * x

fig, axes = plt.subplots(1, 2)

axes[0].fill_between(x, lower, upper, color="#5b7a8c", alpha=0.25,
                     label="90% predictive band")
axes[0].scatter(x, y, color="#8c8c7a", s=14, label="Observed")
axes[0].plot(x, true_line, color="#b06a3b", linestyle="--", linewidth=1.5,
             label="True line")
axes[0].plot(x, mode_curve, color="#6b7f3f", linewidth=2, label="MAP fit")
axes[0].set_xlabel("x")
axes[0].set_ylabel("y")
axes[0].set_title("Bayesian regression fit")
axes[0].legend(frameon=False, fontsize=8)

residuals = y - mode_curve
axes[1].scatter(mode_curve, residuals, color="#6b7f3f", s=14)
axes[1].axhline(0, color="#b06a3b", linestyle="--", linewidth=1.5)
axes[1].set_xlabel("Fitted")
axes[1].set_ylabel("Residual")
axes[1].set_title("Residuals vs fitted")

fig.tight_layout()
plt.show()

inside = (y >= lower) & (y <= upper)
covers_true = (true_line >= lower) & (true_line <= upper)
print(f"observations inside the 90% predictive band: {inside.mean():.4f}")
print(f"ordinates where the band covers the true line: {covers_true.sum()} of {n}")
observations inside the 90% predictive band: 0.8875
ordinates where the band covers the true line: 80 of 80

Reproduction check

The upstream file is a script with no committed outputs, so there are no upstream posterior literals to compare against; the reference values are the true generating parameters. The priors and the parameterization deliberately differ (data-scaled uniform priors, time-index trend), so bit-comparison with the upstream posterior is impossible and the parameter checks are statistical. The exact tier covers what is exactly checkable: the seeded synthetic data (the same Mersenne Twister stream the upstream draws) and cross-language identity of the whole analysis (the R twin asserts the same MAP literals from the same seed).

Quantity Upstream C# This port Status
Seeded data y[0] (seed 123) same MT stream 2.61712675977869 exact
Seeded data y[79] same MT stream 15.89237584375904 exact
Intercept a 2.0 (true) MAP 2.0437 statistical
Slope b 1.4 (true) MAP 1.3916 statistical
sigma 1.2 nominal, 0.9037 realized MAP 0.9185 statistical
90% band covers the true line - 80 of 80 ordinates statistical

The cell below fails the notebook if any value drifts.

# Upstream: examples/bayesian_regression.py (a script with no committed outputs;
# the reference values are the true generating parameters, not upstream posteriors).

# Exact: the seeded synthetic data, identical across Python, R, and the C# library.
assert y[0] == 2.6171267597786905
assert y[-1] == 15.892375843759043

# Exact: cross-language identity of the fit itself (same seed, same core; the R twin
# asserts these same literals).
assert mu_map == 2.043676501381344
assert gamma_map == 0.1761574955229039

# Statistical: recovered parameters near the truth. Priors and parameterization
# deliberately differ from the upstream script, so only closeness can be asserted.
assert abs(mu_map - true_a) < 0.5
assert abs(b_map - true_b) < 0.1
assert 0.7 < sigma_map < 1.2  # tracks the realized noise sd, 0.9037

# Statistical: the 90% predictive band covers the true line everywhere and most
# observations.
assert covers_true.all()
assert inside.mean() > 0.8
print("All reproduction checks passed.")
All reproduction checks passed.
